Product Details
Place of Origin: Jiansu
Brand Name: YUSH
Certification: CE
Model Number: YSV-1A
Payment & Shipping Terms
Minimum Order Quantity: 1set
Packaging Details: Plywood case
Delivery Time: 3 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 300 sets/ month
Voltage:: |
220VAC / 110VAC |
Cutting Thickness:: |
0.8-3.5 Mm |
Cutting Speed:: |
0-1000 Mm / S |
Material Of Blade:: |
SHK-9 High Speed Steel |
Machine Dimension:: |
521 X 1200 X 410 Mm |
Size Of Transfer Belt:: |
1200 X 180 X 127 Mm |
Voltage:: |
220VAC / 110VAC |
Cutting Thickness:: |
0.8-3.5 Mm |
Cutting Speed:: |
0-1000 Mm / S |
Material Of Blade:: |
SHK-9 High Speed Steel |
Machine Dimension:: |
521 X 1200 X 410 Mm |
Size Of Transfer Belt:: |
1200 X 180 X 127 Mm |
Motorized depanel pcb Maestro 4m PCBA Depanel Routing Machine For One Day Lead Time
PCB depaneling with running type
1. Operator foolproof
2. Infrared protection
3. Calibration Blade Set
4. LCD program Control
Specification:
| Model | YSV-1A |
| PCB Cutting Length (mm) | 460/600/1000/1500 |
| Cutting Speed (mm/s) | 100/200/300/500 |
| Cutting Thickness (mm) | 0.6~3.5 |
| Power Supply | 110/220 V |
| Size (mm) | 770*510*450 |
| Weight (Kg) | 55 |
| Blade working life for metal (Year) | 0.5 |
| Blade working life for PCB (Year) | 1 |
| Guarantee (Year) | 1 |
| Delivery (Day) | 1 |
| Ability (Set) | 1000 |
| Min. Order (Set) | 1 |
Detailed Product Description:
1. For electronics, cell phones, computers, PCB, FPC (flexible printed circuit board),LED.
2. Mold make of SKH-11 Steel, Blade is SKH-9(From Japan), rigorous Job.Dedicated
to high strength cutting, and excellent toughness, able to cut metal board.
Technical characteristics:
1. Structural precision, the load evenly, to eliminate internal stress
2. Safe, easy to operate
3. For electronics, cell phones, computers, PCB, FPC (flexible printed circuit board)
Feature:
Motorized depanel pcb Maestro 4m PCBA Depanel Routing Machine For One Day Lead Time
1. Minimize the shearing stress to avoid micro-cracks of the solder joints.
2. Guiding device of the "V-CUT" of the PCB.
3. Ball bearing slideways for easy setting of the PCB edge guides.
4. Ball bearing slideways for easy setting of the height of the tabletop.
5. Easy operating modes: Manual by handwheel, semi-automatic by pressing the start button or fully-automatic by continuous running.
6. Cutters can be re-grinded .
7. The shape of the cutter can be customer made
