SMT Glue Dispenser . Automatic Glue Dispenser Machine
SMT Glue Dispenser . Automatic Glue Dispenser Machine
SMT Glue Dispenser . Automatic Glue Dispenser Machine
SMT Glue Dispenser . Automatic Glue Dispenser Machine
SMT Glue Dispenser . Automatic Glue Dispenser Machine
SMT Glue Dispenser . Automatic Glue Dispenser Machine
SMT Glue Dispenser . Automatic Glue Dispenser Machine
SMT Glue Dispenser . Automatic Glue Dispenser Machine

SMT Glue Dispenser . Automatic Glue Dispenser Machine

Product Details

Place of Origin: Jiangsu, China

Brand Name: YUSH

Model Number: YS-S330

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: $5,000 / set

Get Best Price

Product Details

Product Description
Highlight:

automatic glue dispenser machine

,

SMT glue dispenser machine

,

PCB depaneling glue dispenser

Weight:
75 KG
Working Area:
300*300*60 Mm
Working Humidity:
20~90% No Condensation
Dimensions:
485*505*610 Mm
Voltage:
250W
Glue Pump Viscosity:
Almost All Viscosity
Dispensing Head:
One Or More On Request
Power:
220/110 V
Speed:
Max. 500mm/sec
Dispensing Quantity:
Min. 0.001ml
Resolution:
0.01mm
Repeatability:
+/-0.01mm
Size:
460*450*480 Mm
Weight:
70KG
Core Components:
Motor
Weight:
75 KG
Working Area:
300*300*60 Mm
Working Humidity:
20~90% No Condensation
Dimensions:
485*505*610 Mm
Voltage:
250W
Glue Pump Viscosity:
Almost All Viscosity
Dispensing Head:
One Or More On Request
Power:
220/110 V
Speed:
Max. 500mm/sec
Dispensing Quantity:
Min. 0.001ml
Resolution:
0.01mm
Repeatability:
+/-0.01mm
Size:
460*450*480 Mm
Weight:
70KG
Core Components:
Motor
SMT Glue Dispenser . Automatic Glue Dispenser Machine
SMT Glue Dispenser - Automatic Glue Dispenser Machine
Our SMT glue dispenser is a high-precision automatic dispensing machine designed for various industrial applications requiring accurate adhesive placement.
Key Specifications
  • Compatible with silicone glue, UV glue, AB glue, and more
  • Easy-to-modify holder and programming
  • High quality construction with CE certification
SMT Glue Dispenser . Automatic Glue Dispenser Machine 0 SMT Glue Dispenser . Automatic Glue Dispenser Machine 1
Compatible Materials
Suitable for silicone glue, UV glue, AB glue, EPOXY (black glue), COB black glue, white glue, EMI conductive glue, epoxy resin, instant glue, silver glue, red glue, paste, thermal grease, welding control paste, transparent paint, and more.
Application Capabilities
Can perform dots, draw lines, squares, circles, and various irregular graphics on surfaces, exterior walls, vertical planes, and product gaps.
SMT Glue Dispenser . Automatic Glue Dispenser Machine 2 SMT Glue Dispenser . Automatic Glue Dispenser Machine 3
Technical Specifications
ModelYS-S330
Power220/110 V
Voltage250W
Working Area (X*Y*Z)300*300*60 mm (Customizable)
SpeedMax. 500mm/sec
Dispensing QuantityMin. 0.001ml
Resolution0.01mm
Repeatability+/-0.01mm
Size (L*W*H)460*450*480 mm
Weight70KG
SMT Glue Dispenser . Automatic Glue Dispenser Machine 4 SMT Glue Dispenser . Automatic Glue Dispenser Machine 5
Advanced Features
  • Full automatic robot with 3 or 4 axes
  • Dispensing path can be set in robot or imported from external computer
  • Easy operation with amendable holder and programming
  • Can store multiple independent running programs
  • High precision with well-controlled glue application
  • Configurable with multiple dispensing heads
  • Wide dispensing area capable of handling several products
  • Customizable working table available on request
SMT Glue Dispenser . Automatic Glue Dispenser Machine 6 SMT Glue Dispenser . Automatic Glue Dispenser Machine 7
Industry Applications
  • Electro-acoustic industry: speakers, buzzers, audio, headphones
  • Inductance industries: small transformers, SMD transformers, relays, small coil motors
  • Communications industry: cell phone keyboard, mobile phone shells, radio, telephone, fax
  • Computers, digital products, digital cameras, MP3, MP4, electronic toys
  • Switches, connectors, wire, plug cable
  • Electronics: electronic components, integrated circuits, circuit board solder paste, electronic parts, LCD liquid crystal screens
  • Optics: optical lenses, optical heads
  • Mechanical hardware, battery boxes, trademarks, steam machinery spare parts
  • LED industries
SMT Glue Dispenser . Automatic Glue Dispenser Machine 8 SMT Glue Dispenser . Automatic Glue Dispenser Machine 9
