Professional Spherical LED Aluminum Substrate & COB Ceramic Board for SMT Assembly Line

Product Details

Place of Origin: Guangdong, China

Brand Name: YSUH

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: $9,000 / set

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Professional LED aluminum substrate, COB ceramic board SMT assembly, PCB depaneling machine with warranty


Weight:	230kg	Voltage:	220V
Blade Size:	20043.56mm	Working Pressure:	0.5~0.8Mpa
Cutting Width:	Max 200mm	V-cut Thickness:	One Third Of Plate Thickness
Blades Material:	High Speed Steel, Titanium Coated	Power:	150W
Core Components:	PLC, Motor, Gear	Micro Stress:	About 200
Cutting Stroke:	Below 2mm	Efficiency:	5~6 Times Faster
Machine Type:	Cutting Machine	Gas Hybrid:	Double Straight Knife Slitting
Anti-dwelling Design:	No Safety Concerns

Weight:	230kg
Voltage:	220V
Blade Size:	20043.56mm
Working Pressure:	0.5~0.8Mpa
Cutting Width:	Max 200mm
V-cut Thickness:	One Third Of Plate Thickness
Blades Material:	High Speed Steel, Titanium Coated
Power:	150W
Core Components:	PLC, Motor, Gear
Micro Stress:	About 200
Cutting Stroke:	Below 2mm
Efficiency:	5~6 Times Faster
Machine Type:	Cutting Machine
Gas Hybrid:	Double Straight Knife Slitting
Anti-dwelling Design:	No Safety Concerns

Professional Spherical LED Aluminum Substrate & COB Ceramic Board for SMT Assembly Line

Advanced PCB depaneling equipment specifically designed for COB light source boards and spherical LED aluminum substrates. This system utilizes microcomputer-controlled automatic board feeding for precision cutting operations.

Key Features & Benefits

Microcomputer-controlled automatic board feeding system
Versatile cutting capability for COB substrates, bulb LED aluminum substrates, and ceramic plates
5-6 times faster processing speed compared to traditional board machines
Minimal component stress (approximately 200) during cutting to prevent tin cracking and protect precision parts
Gas hybrid design with double straight knife slitting technology
Ideal for precision PCB board division and depaneling
Scythe work mechanism suitable for various thickness MCPCB with cutting stroke below 2mm
Anti-dwelling structure design ensuring operational safety

Technical Specifications

This specialized equipment is engineered for SMT assembly line applications, providing reliable and efficient depaneling solutions for modern electronic manufacturing requirements.
