Smt Laser Cutting Machine/pcb Board v Cutting Machine

Product Details

Place of Origin: Jiangsu, China

Brand Name: YUSH

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: $12,000-38,000 / set

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                SMT laser cutting machine, PCB board cutting machine, PCB depaneling machine with warranty


Weight:	3500 Kg	Power:	10 KW
Voltage:	220V, 380V	Cutting Speed:	01.0 ~100mm/s
Repetitive Accuracy:	± 0.01mm	Control Mode:	Industrial IPC And PC
Drive Mode:	AC Servomotor	Cutting Accuracy:	± 0.05mm
Spindle Speed:	Max 100000rpm	Laser Wavelength:	355nm
Laser Power:	10W	Maximum Format:	610mm X 500mm
Platform Speed:	50m/min	Positioning Accuracy:	± 3um
Repeatability:	± 1um

Weight:	3500 Kg
Power:	10 KW
Voltage:	220V, 380V
Cutting Speed:	01.0 ~100mm/s
Repetitive Accuracy:	± 0.01mm
Control Mode:	Industrial IPC And PC
Drive Mode:	AC Servomotor
Cutting Accuracy:	± 0.05mm
Spindle Speed:	Max 100000rpm
Laser Wavelength:	355nm
Laser Power:	10W
Maximum Format:	610mm X 500mm
Platform Speed:	50m/min
Positioning Accuracy:	± 3um
Repeatability:	± 1um

Smt Laser Cutting Machine/pcb Board v Cutting Machine

SMT Laser Cutting Machine / PCB Board V-Cutting Machine

YASTM-4C SMT Stencil Laser Cutting Machine by YUSH Technology

About YUSH Technology

YUSH Technology is a leading instrument brand committed to PCB industry equipment research, development, and production. Our FPC ultraviolet laser cutting machines are widely recognized by customers for their precision and reliability.

Applications

The FPC UV laser cutting machine is designed for precision cutting of flexible circuit boards and organic coatings without requiring molds or protective plate fixation. Utilizing high-energy laser sources with precise beam control ensures superior processing speed and accurate machining results.

Key Features

Proprietary control software with intuitive interface, comprehensive functionality, and simple operation
Capable of processing any graphics with different thicknesses and materials, complete hierarchical synchronization
Optimized optical system design ensures high beam quality and reduced focused spot size for precision cutting
High-performance UV laser with optimal wavelength, superior beam quality, and high peak power characteristics
Material processing through decomposition and vaporization rather than melting, resulting in minimal post-processing burrs and small thermal effect
Vacuum sample fixation eliminates need for mold protection plates, improving processing efficiency
Capable of cutting various substrate materials including silicon, ceramic, and glass
Automatic correction, positioning, multi-plate cutting, thickness measurement and compensation functions

Technical Specifications

Laser System

Laser Type: Solid-state UV laser
Wavelength: 355nm
Laser Power: 10W

Processing Capabilities

Maximum Processing Format: 610mm × 500mm (24" × 18")
XY Platform Maximum Speed: 50m/min
Positioning Accuracy: ±3μm
Repeatability: ±1μm
System Precision: ±20μm
Galvanometer Scanning Range: 50mm × 50mm
Cutting Thickness: <1mm

Power & Environmental Requirements

Power Supply: AC220V 50Hz / 2.2KW or Three-phase 380V 50Hz / 5.5KW
Exhaust Requirements: 516m³/h
Ambient Temperature: 20℃ ±2℃
Humidity: <60% RH non-condensing
Ground Amplitude: <5μm
Vibration Acceleration: <0.05g
Ground Pressure: 2200kgf/m²

Control System

Industry-specific control equipment with flexible processing software
Dedicated motion control card and IPC control mode
17-inch monitor with 300G+ hard drive
Supports standard G-code, Gerber data, and CAD formats

Physical Specifications

Specification	Value
Maximum Board Length	610 × 500mm
Package Size	1818mm × 2317mm × 1550mm
Thickness	1mm
Power Supply	AC220V 50Hz / 2.2KW; Three-phase 380V 50Hz / 5.5KW
Working Air Pressure	516m³/h
Weight	3500kg
Scope of Application	All V-CUT SMD PCB FPC boards
