Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades

Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades
Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades

Large Image :  Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades

Product Details:
Place of Origin: Jiangsu,China
Brand Name: YUSH
Certification: CE
Model Number: PCB router machine YSVJ-650
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD1500~10000
Packaging Details: Wooden case
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100sets/month

Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades

Description
Max Cutting Width: 300mm Size: L1300*W400*H1000mm
Power: 220V 50Hz Power Consumption: <2KW
Operating System: WindowS7 Applicable Board: Can Cut LED Panel, Fiberboard, Aluminum Board (more Than 400mm ) And Special Board.
Working Mode: Offline X、Y、Z Axis Drive Mode: Servo Motor Control
Vision System: Vision Automatic Positioning System
High Light:

Windows 7 PCB Router Machine

,

Thickness 3mm PCB Router Machine

,

Multiple Group Blades PCB Router

PCB thickness 0.8-3.0mm/Multiple Group Blades WindowS7 operating system PCB router machine





PCB router machine YSVJ-650



Feature:


1. The shaft of the knives( top and bottom) is design to be an an integral whole, it is convenient to install, pick and place.

2. This machine adopts computer screen control with a counting device which can be preset production. Gap of the cutting tool displayed by the display screen directly.

3. All the v-cut pcb board can be cut by this machine.

4. Pcb board is cut by multiple cutters which can cut several board once.

5. The machine top cutter wheel can be slightly adjust:0-5mm.

6. The distance between the knives can be adjusted, and it is suitable to cut single pcb board within width 15-20mm.

7. Blade is made of SKH51 high speed steel with long service life and wear resistance.

8. Cutting speed can be set and conveniently adjusted by turn-knob.

9. Install conveyer belt, pcb board which is cut can be sent out directly, then docking with the next machine and reducing the times of artificial pick and place. This machine can cut LED panel, fiberboard, aluminum board (more than 400mm ) and special board.

10. With several knives, the machine operates simply and efficiently and is suitable for mass production.


Specification

Power : 220V AC 50HZ



Power consumption:1500w

Size: L1300*W400*H1000mm

Working mode:offline

Process of cutting is unlimited

PBC thickness: 0.8-3.0mm



Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades 0





Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades 1





Specification

Power : 220V AC 50HZ



Power consumption:1500w

Size: L1300*W400*H1000mm

Process of cutting is unlimited

PBC thickness: 0.8-3.0mm



Working mode:offline







Windows 7 Thickness 3mm PCB Router Machine With Multiple Group Blades 2
