Product Details
Place of Origin: China
Brand Name: Yush
Certification: CE
Model Number: YSV-3A
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: USD4200
Packaging Details: plywooden case
Delivery Time: 5-7 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 sets/month
Drive System Motor: |
Stepping Motor |
Cutting Performance: |
500mm / S |
Repeated Accuracy Of Driving System: |
± 0.02mm |
Resolution: |
± 0.01mm |
Drive System Motor: |
Stepping Motor |
Cutting Performance: |
500mm / S |
Repeated Accuracy Of Driving System: |
± 0.02mm |
Resolution: |
± 0.01mm |
YSV-3A-SMT-Desktop-high-speed-spindle Programming mode PCB LED Board Cutting Router
Technical Parameters:
1. Drive system motor: stepping motor
2. Spindle: high speed spindle
3. Cutting performance: 500mm / S
4. Repeated accuracy of driving system: ± 0.02mm
5. Cutting speed: max. 100mm / s depends on circuit board material and cutting quality
6. Resolution: ± 0.01mm
7. Configuration: X, Y, Z three axes, journey: 300 * 300 * 100mm, journey can also be customized.
8. Repeated cutting accuracy: < 0.05mm, for the contour of straight line and curve
9. Circuit Board Location: Special or Standard Fixtures
10. Loading and unloading mode: manual mode
11. Thickness of circuit board: 0.4mm-4mm
12. Safety Settings: Emergency Stop Switch of the whole machine, Emergency Stop Switch of the spindle, Overheat of the spindle motor and overload detection of the servo motor
13. Spindle motor:
Power: 0.3kw
Maximum speed: 60000 rpm
Cooling mode: air cooling
| Machine size: | 650 * 550 * 615mm |
| Weight: | 73kg |
| Programming mode: | keypad input teaching |
| Data storage capacity: | 100-200 groups of files |
| Control mode: |
microcomputer control, online teaching programming, CAD file import |
| Transmission mechanism: |
guide rail + screw rod (Taiwan) |
16. Programming mode: keypad input teaching
17. Data storage capacity: 100-200 groups of files
18. Control mode: microcomputer control, online teaching programming, CAD file import
19. Transmission mechanism: guide rail + screw rod (Taiwan)
20. Vacuum cleaner: 1.5kw, 220V; size: 710 * 390 * 680mm; it can work continuously for 24 hours.
21. Vacuum method: lower vacuum
22. Safety measures: equipped with protective cover
16. Programming mode: keypad input teaching
17. Data storage capacity: 100-200 groups of files
18. Control mode: microcomputer control, online teaching programming, CAD file import
19. Transmission mechanism: guide rail + screw rod (Taiwan)
20. Vacuum cleaner: 1.5kw, 220V; size: 710 * 390 * 680mm; it can work continuously for 24 hours.
21. Vacuum method: lower vacuum
22. Safety measures: equipped with protective cover
16. Programming mode: keypad input teaching
17. Data storage capacity: 100-200 groups of files
18. Control mode: microcomputer control, online teaching programming, CAD file import
19. Transmission mechanism: guide rail + screw rod (Taiwan)
20. Vacuum cleaner: 1.5kw, 220V; size: 710 * 390 * 680mm; it can work continuously for 24 hours.
21. Vacuum method: lower vacuum
22. Safety measures: equipped with protective cover
