AC220v Automatic Pcb Cleaning Machine 12 Nozzles In One Time

AC220v Automatic Pcb Cleaning Machine 12 Nozzles In One Time

  • High Light

    pcb cleaning equipment

    ,

    ultrasonic pcb cleaning machine

  • Item Model Number
    YS-12
  • Air Supply
    0.5~0.7Mpa
  • Power Supply
    AC220V,1A,250W
  • Liquid
    DI Water Or Purified Water
  • Jet Pressure
    ≤0.55Mpa
  • Place of Origin
    china
  • Brand Name
    YUSH
  • Certification
    CE
  • Model Number
    YS-12
  • Minimum Order Quantity
    1set
  • Packaging Details
    wooden packaging- L665*W555*H475(mm)
  • Payment Terms
    T/T, L/C
  • Supply Ability
    100month

AC220v Automatic Pcb Cleaning Machine 12 Nozzles In One Time



AC220v Automatic Pcb Cleaning Machine 12 Nozzles In One Time



Product Feature:

1. Clean 12 nozzles in one time, quicker and more efficient

2. Replace traditional manual clean, avoid troubles caused by ultrasonic cleaner, reduce rejection rate.

3. To clean the dirt completely which ultrasonic cleaner can not deal with.

4. cleaning result will not affect by the smaller and smaller nozzle.

5. Thoroughly clean 99% dirt on nozzle, extend the lifespan of nozzle.

6. Protect the coating surface of nozzle and its reflection panel.

7. No solvent, only use environmentally friendly DI water or purified water .

8. Easy operation.

9. Applicable to all kinds of Mounter nozzles.



AC220v Automatic Pcb Cleaning Machine 12 Nozzles In One Time 0


Machine SpecS:



Item Model Number YS-12
Air supply 0.5~0.7Mpa
Power supply AC220V,1A,250W
Liquid DI water or purified water
Jet pressure ≤0.55Mpa
Liquid consumption ≤150cc/hour
Nozzle range
Min01005~Max inner diameter ¢2.0mm
Jig spec 12 holes
Machine size L665*W555*H475(mm)
Machine weight 70kg
