Product Details
Place of Origin: Jiangsu
Brand Name: YUSH
Certification: CE
Model Number: YSL-1200
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: USD1000~5800
Packaging Details: Wooden case
Delivery Time: 5-10 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100Sets/ month
Setting Fixture: |
2 Stations |
Working Area: |
320mm, Y: 320mm, Z: 60mm |
PCB Thickness: |
0.5 To 3.0 Mm |
Precision Of Cutting: |
± 0.10 Mm |
Setting Fixture: |
2 Stations |
Working Area: |
320mm, Y: 320mm, Z: 60mm |
PCB Thickness: |
0.5 To 3.0 Mm |
Precision Of Cutting: |
± 0.10 Mm |
PCB Router Machine Morning Star Spindle,PCB routing depaneling YS-1200
1. Manual loading/unloading processing
2. 2-way sliding working exchanger to limit the idle time and simultaneously loading and unloading to reaches the utmost output value.
3. Friendly touch panel with 10X CCD camera to minimize the time of programming
4. Auto fiducial mark point check and cutting route auto compensation to ensure the cutting accuracy
5. Auto router bit check to prevent the bit break incomplete cutting.
Specification:
| Setting Fixture | 2 stations |
| Working Area | X: 320mm, Y: 320mm, Z: 60mm |
| Cutting Area | Max: X: 320mm, Y: 320mm Min: X: 100mm, Y: 100mm Z: 15mm |
| PCB Thickness | 0.5 to 3.0 mm |
| PCB Component Height | Top side: 15mm Bottom side: 45mm(with specific jig) |
| Router Bit Diameter | 0.8 ~ 2.0 mm(Option: Over 2.0mm) |
| Precision of Cutting | ± 0.10 mm |
| Positioning Accuracy | ± 0.01mm |
| Dimensions | (W)2002mm x (D)1279mm x (H)1716mm + 578mm signal tower |
| Weight | approx. 500 Kg |
