Durable Table Pcb Depaneling Router For 450 * 350mm Printed Circuit Board

Durable Table Pcb Depaneling Router For 450 * 350mm Printed Circuit Board
Durable Table Pcb Depaneling Router For 450 * 350mm Printed Circuit Board Durable Table Pcb Depaneling Router For 450 * 350mm Printed Circuit Board

Large Image :  Durable Table Pcb Depaneling Router For 450 * 350mm Printed Circuit Board

Product Details:
Place of Origin: Jiangsu
Brand Name: YUSH
Certification: CE
Model Number: YSVC-650
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 1000
Packaging Details: Wooden case
Delivery Time: 10 days
Payment Terms: D/P, D/A, L/C, T/T
Supply Ability: 100/ month

Durable Table Pcb Depaneling Router For 450 * 350mm Printed Circuit Board

Description
PCB Material:: FR1, FR4, MCPCB PCB Size:: 450*350mm
Routing Bit:: 0.8/1.2/1.5/1.8/2.0mm Manipulator Repeatability: ±0.02mm
Board Positioning: Dual Workstation With Nest Fixture Or Pin Fixture Dimensions: 1220mm*1450mm*1420mm
Weight:: 550KG
High Light:

pcb depanelizer

,

pcb separator machine

Specifications:



Dimensions(W*D*H): 1220mm*1450mm*1420mm
Weight: 550KG
Height offset: 60~110mm
Motor type: JiaBao series
Positioning repeatability: 0.001mm
Axis working area(max): 680mm*360mm*50mm
PCB fixation: standard,specialization
PCB loading/unloading: manual
PCB size (max): 322mm*322mm
PCB thick (max): 5mm
Rigidity fixturing: standard
Fixturing fixation: machinery
Power: 400W
Spindle: 50000rpm/min
Protect: self/wind cooling
Change cutter: Specialization

PCB Routing Equipment,CW-F01

PCB Routing Equipment,CW-F01



Advantages:

1. Smooth cutting finish only by router cutting .
2. There is little distortion on PCB during cutting because using high-frequency spindle motor . It is 1 / 10 of pressing , 1 / 100 of breaking by hand .
3. One-touch program changeover .
4. Able to cut liner and arc with router machine , diminish the restriction on PCB design .
5. Read QR code or JIG BIT auto select cutting program , or check accordance between cutting program and JIG .
6. Powerful Dust Collection minimized dust adhesion on PCB .
7. Developed high performance router bit that expanded bit life and relief littering .



8. Cut down PCB cost because need not making V-groove on PCB
