Automatic V-Cut Aluminum Plate PCB LED Cutting Machine 2600 * 580mm * 980mm

Automatic V-Cut Aluminum Plate PCB LED Cutting Machine 2600 * 580mm * 980mm

  • High Light

    pcb depaneling equipment

    ,

    v cut pcb depaneling machine

  • The Use Of Voltage
    110/220VAC
  • Scoreboard Thickness
    1.0-3.2mm
  • The Scoreboard Speed
    0-400mm / S
  • Element Height Limit
    15mm
  • Host Dimensions
    (L) 2600 * (W) 580mm * (H) 980mm
  • Special Parts For Ultra-high Height Up To
    70mm
  • Place of Origin
    JUANGSU
  • Brand Name
    YUSH
  • Certification
    CE
  • Model Number
    YSVJ-650
  • Minimum Order Quantity
    1 set
  • Price
    38000-40000 USD
  • Packaging Details
    Plywooden case
  • Delivery Time
    3 days
  • Payment Terms
    D/P, Western Union, D/P, L/C, T/T

Automatic V-Cut Aluminum Plate PCB LED Cutting Machine 2600 * 580mm * 980mm

Factory direct automatic PCB V-cut specification, aluminum plate PCB V-cut specification, 0.6MM PCB V-cut specification



Features for pcb separator :



1), 10 pairs of blades is available

2), Of the blades is adjusted toindividual PCB

3), Sensors are used to monitor the separating process

4), The PCBs are placed either by hand or they feed automatically by a loading station.

5), Easy operating

6), Could be adjusted according to PCB sizes and customers' requirements

7), Could be customized made as customers' request



Specification:

Automatic V-Cut Aluminum Plate PCB LED Cutting Machine 2600 * 580mm * 980mm 0



Separation speed 100-220 mm/s
Panel length 100-570mm
Panel width Max 310mm
Width off-cut min 3mm
Number of blades max 10 pairs
Width of PCBs 10-300mm
Component height Component side: max 30mm
Solder side: max 10mm





Automatic V-Cut Aluminum Plate PCB LED Cutting Machine 2600 * 580mm * 980mm 1
