Working size
|
Working Area
|
350 X350 mm ( Customizable large size)
|
|
PCB Thickness
|
0.3~3.5mm
|
|
Hardware brand
|
Waste collection methods
|
Dust collection box
|
|
Dust collection method
|
Upper or Lower Vacuum
|
|
Dust collection
|
Upper vacuum 2HP-3HP/Lower vacuum
|
|
box parameters
|
3HP-5HP
|
|
Sensor Switch Brand
|
Panasonic Japan
|
|
Servo motor brand
|
Panasonic Japan
|
|
Electrostatic ion wind gun brand
|
Taiwan
|
|
Guideway Brand
|
Taiwan PMI
|
|
Screw brand
|
Taiwan TBI grinding grade
|
|
CCD camera brand
|
Germany BASLER
|
|
Spindle Brand
|
Japan NAKANISHI
|
|
Computer host brand
|
ASUS brand host
|
|
Machine weight
|
840KG
|
|
Security grating
|
Taiwan
|
|
Electric
|
Power supply
|
AC220/380V50/60HZ three-phase
|
|
Compressed air
|
0.4-0.6 MPA (with filter)
|
| |
Operating
|
Chinese/English Optional
|
|
System
|
|
|
Software control method
|
PC+ Industrial Control System Control
|
|
Programming methods
|
Computer programming, AOI scanning and editing programs faster and more accurate
|
|
Warning light
|
Three-color sound and light alarm (normal work, waiting for test, fault alarm)
|
|
With fault alarm: air pressure instability, blocking, collision
|
|
Safe production
|
Produce order mode production, four-level password protection (automatic, manual, sensor protection, etc.)
|
|
Technical Parameters
|
Statistics function
|
Both left and right board with statistics function
|
|
Information management function
|
Support MES information system to seamlessly connect equipment and information management, Open Ethernet Interface, and supports TCP/IP network communication protocol, and necessary related software and programs; Open the BAR CODE function port.
|
|
X.Y, Z, axis drive
|
Servo motor + screw, guide rail
|
|
Worktable input and output methods
|
Servo motor + screw, guide rail
|
|
Cutting product requirements
|
Left and right worktables can separate different products at the same time
|
|
Cutting height requirements
|
Left and right worktables can separate different heights and products at the same time
|
|
MARK point identification requirements
|
MARK points of different shapes can be identified, and MARK points can be freely set before each division.
|
|
LED aperture requirements
|
LED aperture brightness can be adjusted in software
|
|
Camera
|
Software controlled camera moves up and down
|
|
PCB positioning and adjustment methods
|
Universal fixture, positioning PIN, tool fixture
|
|
Milling cutter diameter rang
|
0.8-3.0mm
|
|
Milling cutter management
|
The software can automatically adjust the height according to the thickness of the PCB board and the toughness length of the cutter to extend the service life of the cutter and standard tool detection.
|
|
MES docking
|
Open MES docking port function
|
|
BAR CODE scan
|
Open BAR CODE Scan Port Function
|
|
Cutting speed
|
0-100mm/S adjustable per second
|
|
Working table
|
two worktables
|
|
Cutting function
|
Can cut straight, curved, L-shaped, U-shaped
|
|
Trouble shooting
|
Software can detect failure points, have I/O port detection capabilities, and have detailed alerts
|
|
Service
|
Machine warranty 15 months. Our after-sales points are Suzhou, Dongguan, the United States, Brazil, Britain, France, and Turkey. Welcome to be our foreign agent.
|
