Product Details
Place of Origin: Jiangsu,China
Brand Name: YUSH
Certification: CE
Model Number: YSL-1000
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: USD 80000~100000
Packaging Details: Wooden case
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T
Supply Ability: 30sets/month
Model: |
YSL-1000/YSL-1000A |
Cutting Area: |
250mm*270mm/440*380mm |
Material Thickness: |
<0.1mm |
Voltage/Power Requirement: |
AC220V 50/60Hz |
Machine Weight: |
450KG/2000KG |
Humidity: |
<60% |
Model: |
YSL-1000/YSL-1000A |
Cutting Area: |
250mm*270mm/440*380mm |
Material Thickness: |
<0.1mm |
Voltage/Power Requirement: |
AC220V 50/60Hz |
Machine Weight: |
450KG/2000KG |
Humidity: |
<60% |
250mm*270mm Weight 450KG <1mm thickness AC220V/3KW PCB board laser dispenser
1. The shaft of the knives( top and bottom) is design to be an an integral whole, it is convenient to install, pick and place.
2. This machine adopts computer screen control with a counting device which can be preset production. Gap of the cutting tool displayed by the display screen directly.
3. All the v-cut pcb board can be cut by this machine.
4. Using the machine to cut, reduce stress, prevent the solder joint cracking.
5. The distance between the knives can be adjusted, and it is suitable to cut single pcb board within width 15-20mm.
6. Blade is made of SKH51 high speed steel with long service life and wear resistance.
7. Cutting speed can be set and conveniently adjusted by turn-knob.
8. Install conveyer belt, pcb board which is cut can be sent out directly, then docking with the next machine and reducing the times of artificial pick and place. This machine can cut LED panel, fiberboard, aluminum board (more than 400mm ) and special board.
Working Voltage:220v
Dimension: L1300*W400*H1000mm
Weight : 50 kg
Process of cutting is unlimited
PBC thickness: 0.8-3.0mm
Applicable board: can cut LED panel, fiberboard, aluminum board (more than 400mm ) and special board.
PLS contact us if you have demand of the PCB machine.
